Photo #: 80-G-105497

Camouflage Measure 33, Design 6D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for light cruisers of the CL-55 (Cleveland) class.
Ships known to have worn this scheme included USS Birmingham (CL-62) and USS Vicksburg (CL-86).
This plan, showing the ship's port side, is dated 19 January 1944, and was approved by Captain Logan McKee, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 114KB; 1200 x 600 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
