Photo #: 80-G-109721

Camouflage Measure 31-32-33 Series, Design 18D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for heavy cruisers of the CA-68 (Baltimore) class.
Ships known to have worn this pattern (in Measures 32 and 33) included USS Canberra (CA-70), USS Quincy (CA-71) and USS Pittsburgh (CA-72).
This plan, showing the ship's starboard side, stern, superstructure ends, and exposed decks, is dated 30 December 1943 and was approved by Captain Henry A. Ingram, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 134KB; 1500 x 715 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
