Camouflage Measure 32v1, Design 1D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for light cruisers of the Cleveland (CL-55) class, circa 1943.
This pattern was applied to USS Houston (CL-81) and USS Miami (CL-89). Modified to use the lighter tones of Measure 33, it was also applied, at least on the port side, to USS Columbia (CL-56).
This plan shows the ship's starboard side, stern, superstructure ends, and exposed decks.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 104KB; 1200 x 595 pixels
