Online Library of Selected Images -- Picture Data

Photo #: 80-G-162036

Camouflage Measure 31-32-33 series, Design 16D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for escort ships of the DE-51 (Buckley) class.
This plan shows the ship's starboard side, superstructure ends and exposed decks. It was approved by Captain Henry A. Ingram, USN, and probably was prepared in late 1943 or early 1944.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 141KB; 1200 x 635 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
