Photo #: 80-G-165768

Camouflage Measure 33, Design 3D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for small aircraft carriers of the CVL-22 class.
This plan, approved by Captain Logan McKee, USN, is dated 27 January 1944. It shows the ship's port side.
USS Belleau Wood (CVL-24) and USS Monterey (CVL-26) are known or reported to have worn this camouflage design.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 101KB; 1500 x 425 pixels
