Photo #: 80-G-170024

Camouflage Measure 32-33 series, Design 8A


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for small aircraft carriers of the CVL-22 (Independence) class.
This plan, approved by Captain Henry A. Ingram, USN, is dated 9 December 1943. It shows the ship's port side.
USS Independence (CVL-22) and USS Bataan (CVL-29) were painted in this camouflage design, but the colors applied are not specified on the drawing, and may have varied.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 134KB; 1500 x 475 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
