Photo #: 80-G-172534

Camouflage Measure 33, Design 12L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for tank landing craft of the LCT(6) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 19 April 1944. It shows the vessel's starboard side, the port side of her tank deck's interior, her bow, stern, superstructure ends and exposed decks.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 163KB; 1200 x 935 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
