Photo #: 80-G-173480

Camouflage Measure 32, Design 13T


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for transports of the AP-130 (Maritime Commission type C4-S-A1) class.
This plan, approved by Commander William C. Latrobe, USN, is dated 17 May 1944. It shows the ship's port side.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 124KB; 1200 x 810 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
