Photo #: 80-G-174542

Camouflage Measure 32, Design 3D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for gasoline tankers of the AOG-1 (Patapsco) class.
This plan, approved by Captain Logan McKee, USN, is dated 17 February 1944. It shows the ship's starboard side and superstructure ends.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 109KB; 1200 x 720 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
