Photo #: NH 99985-A-KN (color)

USS Machias (Gunboat # 5)
and
USS Castine (Gunboat # 6)

General appearance plan, with decorated mount, showing the ships' preliminary design. It was presented to the Secretary of the Navy by the Chief Constructor, circa the early 1890s.
See Photo # NH 99985 for a black & white reproduction of the plan alone.

Courtesy of the Naval Historical Foundation.

U.S. Naval Historical Center Photograph.

Online Image: 77KB; 740 x 640 pixels



Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
