Photo #: 19-N-104889

Camouflage Measure 33, Design 3D(ex)


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for escort ships of the Buckley (DE-51) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 7 September 1944. It shows the ship's port side.
Note that this camouflage scheme calls for painting the ship's starboard side in the darker tones of Measure 32.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 153KB; 1200 x 705 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
