Photo #: S-511-31
"Net Layer"
Preliminary design plan prepared for the General Board as part
of a net layer study.
This drawing, dated 22 July 1940 (with modifications of 20 August
1940), is for a 3000-ton (light displacement) ship with a length
(between perpendiculars) of 360 feet.
Scale of the original drawing is 1/16" = 1'.
The original plan is in the 1939-1944 "Spring Styles Book"
held by the Naval Historical Center.
U.S. Naval Historical Center Photograph.
