Photo #: S-511-49

"100 ft. Tank Landing Craft - Design Study"


Preliminary design plan prepared during examination of landing craft proposals.
This plan, dated 21 January 1942, is for a 112.5-ton vessel, similar to the LCT(5), but with two assembly sections instead of three.
Scale of the original drawings is 1/4" = 1'.

The original plan is in the 1939-1944 "Spring Styles Book" held by the Naval Historical Center.

U.S. Naval Historical Center Photograph.

Online Image: 304KB; 2500 x 1285 pixels
