Photo #: S-511-52

"20 Knot Oiler - Preliminary Study"


Preliminary design plan prepared for the General Board as part of a study of high speed oilers.
This drawing, dated 21 March 1942, is for a 28,000-ton (displacement) ship with a length (between perpendiculars) of 600 feet, capable of carrying a cargo of 13,000 tons of oil at a sustained speed of 20 knots.
Scale of the original drawing is 1/32" = 1'.

The original plan is in the 1939-1944 "Spring Styles Book" held by the Naval Historical Center.

U.S. Naval Historical Center Photograph.

Online Image: 297KB; 2500 x 1525 pixels
