Photo #: 80-G-160562

Camouflage Measure 32, Design 13D


Drawing prepared by the Bureau of Ships, circa 1943, for a camouflage scheme intended for destroyers of the Fletcher (DD-445) class.
This plan shows the ship's port side, stern and superstructure ends. It was approved by Captain Henry A. Ingram, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 95KB; 1200 x 520 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
