Photo #: 80-G-176510 Camouflage Measure 32, Design 3D Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the DD-364 (Mahan) class. The basic ship drawing applies to USS Cassin (DD-372) and USS Downes (DD-375). The latter was reportedly painted in this camouflage design. This plan, approved by Captain Torvald A. Solberg, USN, appears to be dated 9 August 1944. It shows the ship's starboard side, superstructure ends and exposed decks. Official U.S. Navy Photograph, now in the collections of the National Archives. Online Image: 98KB; 1200 x 625 pixels Reproductions of this image may also be available through the National Archives photographic reproduction system. |
|
