Photo #: 19-N-104904

Camouflage Measure 32, Design 3Da


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for escort ships of the John C. Butler (DE-339) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 13 November 1944. It shows the ship's starboard side, horizontal surfaces and superstructure ends.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 157KB; 1200 x 855 pixels
