Online Library of Selected Images:
-- SHIPS of the GERMAN NAVY --

Scharnhorst (Battleship, 1939-1943) --
Views on Board the Ship


This page features or provides links to views taken on board the German battleship Scharnhorst.

For more images taken on board Scharnhorst, see:

  • Scharnhorst -- Views on Board the Ship (Part II).

    For further pictorial coverage of Scharnhorst, see:

  • Scharnhorst (Battleship, 1939-1943).


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."

    Click on the small photograph to prompt a larger view of the same image.

    Photo #: NH 101571

    Scharnhorst
    (German Battleship, 1939)

    View looking aft on the foredeck, with anchor handling gear in the foreground and two triple 283mm gun turrets beyond. Taken during the winter of 1939-40, at Kiel.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 9.

    U.S. Naval Historical Center Photograph.

    Online Image: 82KB; 505 x 765 pixels


    Photo #: NH 102536

    Scharnhorst
    (German Battleship, 1939)

    View of the after 283mm (11") triple gun turret and its aircraft catapult, circa winter 1939-40. View looks forward, with the tripod mainmast and naval ensign in the background.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 14.

    U.S. Naval Historical Center Photograph.

    Online Image: 84KB; 580 x 765 pixels


    Photo #: NH 102531

    Scharnhorst
    (German Battleship, 1939)

    Detail view of the rangefinder hood on the right side of the after 283mm (11") gun turret, during the winter 1939-40. View looks forward, with the ship's mainmast and flag visible in the background.
    Note light coating of snow or ice on the turret.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 16.

    U.S. Naval Historical Center Photograph.

    Online Image: 64KB; 740 x 525 pixels


    Photo #: NH 97507

    German 150mm twin gun turret


    The port forward 150mm turret of the battleship Gneisenau or Scharnhorst, seen from ahead, circa 1939-40. Single-mounted 150mm guns are beyond, at main deck level, with 105mm twin anti-aircraft guns above.
    This is a halftone image, clipped by the U.S. Office of Naval Intelligence from the contemporary German booklet "Deutsche Seemacht".

    U.S. Naval Historical Center Photograph.

    Online Image: 70KB; 740 x 385 pixels


    Photo #: NH 102530

    Scharnhorst
    (German Battleship, 1939)

    Firing her forward 283mm (11") guns, during exercises in the winter of 1939-40.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 16.

    U.S. Naval Historical Center Photograph.

    Online Image: 64KB; 740 x 530 pixels


    Photo #: NH 83099-KN (Color)

    Scharnhorst (German battleship, 1939-1943)

    Taking water over the bow while steaming in heavy seas, possibly during the Atlantic sortie of January-March 1941.
    A 150mm twin gun turret is in the foreground.
    Note: This is a screened image, taken from a contemporary publication. It has some abrasion damage in the upper center.

    U.S. Naval Historical Center Photograph.

    Online Image: 134KB; 740 x 550 pixels


    Photo #: NH 102544

    Scharnhorst
    (German Battleship, 1939)

    The ship's forward control tower, with a 10.5-meter rangefinder at its top, seen from abreast the funnel looking forward. Photographed at Kiel or Wilhelmshaven during the winter of 1939-40.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 14.

    U.S. Naval Historical Center Photograph.

    Online Image: 56KB; 510 x 765 pixels


    Photo #: NH 102545

    Scharnhorst
    (German Battleship, 1939)

    View from the foretop, looking down at the base of the funnel, during the winter of 1939-40.
    Note crewmen working on what appears to be a minesweeping paravane in the lower part of the image.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 22.

    U.S. Naval Historical Center Photograph.

    Online Image: 89KB; 740 x 530 pixels


    Photo #: NH 102546

    Scharnhorst
    (German Battleship, 1939)

    View of the mainmast, looking up from the platform below. Probably photographed in 1939-40, possibly during early 1940.

    Copied from the contemporary German photo album "Meine Kriegserinnerungen auf Schlachtschiff Scharnhorst", page 24.

    U.S. Naval Historical Center Photograph.

    Online Image: 93KB; 740 x 500 pixels



    For more images taken on board Scharnhorst, see:

  • Scharnhorst -- Views on Board the Ship (Part II).

    For further pictorial coverage of Scharnhorst, see:

  • Scharnhorst (Battleship, 1939-1943).


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."
