Photo # NH 98889:  Shock mounted coffee maker on board USS Atlanta, 1964

Online Library of Selected Images:
-- U.S. NAVY SHIPS --

USS Atlanta (IX-304), 1964-1970 --
Views on board the Ship


This page features selected views taken on board USS Atlanta (IX-304).

For other images concerning this ship, see:

  • USS Atlanta (IX-304, formerly CL-104).


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."

    Click on the small photograph to prompt a larger view of the same image.

    Photo #: NH 98885

    USS Atlanta (IX-304)


    The ship's two "macks", seen from forward while she was completing conversion to a weapons effects test ship at the Hunters' Point Naval Shipyard, San Francisco, California, circa October 1964.
    The original picture caption, released by 12th Naval District Office of Public Information, reads: "The two masts atop the DLG (guided missile frigate) deck houses are identical in appearance, but, like the deck houses themselves, the forward one is designed specifically for blast resistance."

    Official U.S. Navy Photograph, from the collections of the Naval Historical Center.

    Online Image: 92KB; 590 x 765 pixels


    Photo #: NH 98888

    USS Atlanta (IX-304)


    Stress measuring device mounted on one of Atlanta's masts, photographed as she was completing conversion to a weapons effects test ship at the Hunters' Point Naval Shipyard, San Francisco, California, circa October 1964.
    The original picture caption, released by 12th Naval District Office of Public Information, reads: "Several hundred of the measuring devices are placed throughout the ship. They are calibrated to measure the amount of stress the blasts impose on the ship and what, if any, damage was done."

    Official U.S. Navy Photograph, from the collections of the Naval Historical Center.

    Online Image: 74KB; 595 x 765 pixels


    Photo #: NH 98890

    USS Atlanta (IX-304)


    Shock mounted data recorders on board Atlanta, photographed as she was completing conversion to a weapons effects test ship at the Hunters' Point Naval Shipyard, San Francisco, California, circa October 1964.
    The original picture caption, released by 12th Naval District Office of Public Information, reads: "The measuring devices channel the desired data to shock mounted recorders deep in the ship. The shock mounting system ensures the continued recording of data during the tests."

    Official U.S. Navy Photograph, from the collections of the Naval Historical Center.

    Online Image: 125KB; 595 x 765 pixels


    Photo #: NH 98887

    USS Atlanta (IX-304)


    Shock mounting system for equipment mounted on board Atlanta, photographed as she was completing conversion to a weapons effects test ship at the Hunters' Point Naval Shipyard, San Francisco, California, circa October 1964.
    The original picture caption, released by 12th Naval District Office of Public Information, reads: "The shock mounted recorders are suspended on 'rubber rope' between the ceiling and deck. Regardless of the shock the ship receives, the equipment will float free insuring accurate recording."

    Official U.S. Navy Photograph, from the collections of the Naval Historical Center.

    Online Image: 135KB; 740 x 610 pixels


    Photo #: NH 98889

    USS Atlanta (IX-304)


    Shock mounted coffee maker on board Atlanta, photographed as she was completing conversion to a weapons effects test ship at the Hunters' Point Naval Shipyard, San Francisco, California, circa October 1964.
    The original picture caption, released by 12th Naval District Office of Public Information, reads: "Recording equipment isn't the only item shock mounted in Atlanta. When all loose gear is stowed for the tests, Atlanta sailors can still get a cup of hot coffee."

    Official U.S. Navy Photograph, from the collections of the Naval Historical Center.

    Online Image: 108KB; 595 x 765 pixels
