Photo # NH 76569:  USS Utah's pilothouse and bridges, 21 January 1919

Online Library of Selected Images:
-- U.S. NAVY SHIPS --

USS Utah (Battleship # 31, later BB-31 and AG-16) -- Onboard & Closeup Views, Part I (Exterior Views)


This page features exterior views taken on board USS Utah, or views of her structure seen closeup, throughout her career.

For other images taken on board this ship, see:

  • USS Utah (Battleship # 31, later BB-31 and AG-16) -- On Board Views, Part II (Interior Views).

    For links to more pictures of USS Utah, see:

  • USS Utah (Battleship # 31, later BB-31 and AG-16), 1911-1941.


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."

    Click on the small photograph to prompt a larger view of the same image.

    Photo #: NH 104758

    USS Utah
    (Battleship # 31)

    Halftone reproduction of a photograph taken on board the ship, looking toward the bow from her bridge, circa 1919. Note her forward twelve-inch twin gun turrets.
    This image was published in 1919 by A.M. Simon, 324 E. 23rd St., New York City, as one of ten photographs in a "Souvenir Folder" of views concerning USS Utah.

    Donation of Dr. Mark Kulikowski, 2007.

    U.S. Naval Historical Center Photograph.

    Online Image: 74KB; 740 x 500 pixels


    Photo #: NH 76569

    USS Utah (AG-16)


    Photograph of her pilothouse and bridges, taken at the New York Navy Yard, 21 January 1919. View looks aft from atop her forward 12" gun turret, with turret # 2 in the foreground.
    Note searchlights and concentration dial mounted on Utah's "cage" foremast, and bearing markings painted on the turret base.

    U.S. Naval Historical Center Photograph.

    Online Image: 81KB; 570 x 765 pixels


    Photo #: NH 79494

    USS Utah (AG-16)


    Closeup view of the main masthead, prior to World War I, with sailors in gunfire spotting positions and the U.S. flag flying from the gaff.

    Halftone reproduction, copied from United States Navy Illustrated, published in New York in 1917.

    U.S. Naval Historical Center Photograph.

    Online Image: 124KB; 740 x 460 pixels


    Photo #: NH 61262

    USS Utah (AG-16)


    View looking forward from atop # 4 gun turret, while coaling simultaneously from two colliers at the rate of 841 tons per hour, prior to World War I. The ship's band is stationed on top of # 3 12" gun turret.
    Note Utah's searchlights and the boat cranes flanking her "cage" mainmast.

    U.S. Naval Historical Center Photograph.

    Online Image: 89KB; 740 x 470 pixels


    Photo #: NH 104759

    USS Utah
    (Battleship # 31)

    Halftone reproduction of a photograph taken on board the ship, looking forward on the port side from alongside her after twelve-inch gun turret, circa 1919.
    Note the life rafts mounted on the turret's side.
    This image was published in 1919 by A.M. Simon, 324 E. 23rd St., New York City, as one of ten photographs in a "Souvenir Folder" of views concerning USS Utah.

    Donation of Dr. Mark Kulikowski, 2007.

    U.S. Naval Historical Center Photograph.

    Online Image: 51KB; 740 x 500 pixels


    Photo #: NH 105767

    USS Utah
    (Battleship # 31)

    Firing her after (Turret # 5) 12-inch guns during target practice, circa 1918.
    The original image is printed on post card ("AZO") stock.
    Note the 3"/50 anti-aircraft gun mounted atop Utah's port side boat crane.

    Donation of Charles R. Haberlein Jr., 2008.

    U.S. Naval Historical Center Photograph.

    Online Image size: 55KB; 740 x 450 pixels


    Photo #: NH 105768

    USS Utah
    (Battleship # 31)

    Crew members atop the ship's # 5 (aftermost) twelve-inch gun turret, circa 1918. Annotations on the image identify (from left to right): turret pointer's periscope, fore and main tops on masts (with identities reversed -- the main mast is the nearer), radio aerials and supporting tripod, and speed cones.
    Note the triangular baffles mounted on the masts. These were a measure to confuse coincidence rangefinders, which contemporary intelligence erroneously believed were the type used by the German navy.
    See Photo # NH 105768-A for a reproduction of the original card's reverse, with a message concerning this anti-rangefinding measure.
    The original image is printed on post card ("AZO") stock.

    Donation of Charles R. Haberlein Jr., 2008.

    U.S. Naval Historical Center Photograph.

    Online Image size: 71KB; 740 x 470 pixels


    Photo #: NH 89730

    USS Utah (BB-31)


    Crew of a 5"/51 secondary battery gun in action during early 1920s exercises.
    Note gas masks in use, and breeches of two 3-pdr saluting guns at the bottom of the picture.

    Courtesy of Edward Page, 1979.

    U.S. Naval Historical Center Photograph.

    Online Image: 83KB; 740 x 595 pixels


    Photo #: NH 104755

    USS Utah
    (Battleship # 31)

    Halftone reproduction of a photograph showing enlisted men lined up for mess, circa 1919. Note the mess pails carried by several of these Sailors.
    This image was published in 1919 by A.M. Simon, 324 E. 23rd St., New York City, as one of ten photographs in a "Souvenir Folder" of views concerning USS Utah.

    Donation of Dr. Mark Kulikowski, 2007.

    U.S. Naval Historical Center Photograph.

    Online Image: 94KB; 740 x 505 pixels


    Photo #: NH 49056

    President-Elect Herbert Hoover


    On board USS Utah (BB-31) in late December 1928, while returning to the United States from his South American tour.
    To Mr. Hoover's right is George Akerson, his personal secretary.
    Note 3"/50 gun barrel at right.

    Courtesy of Commander Harold C. Train, USN, 1930.

    U.S. Naval Historical Center Photograph.

    Online Image: 67KB; 430 x 765 pixels


    Photo #: NH 54736

    Secretary of the Navy Charles Edison


    Wearing communications headphones, on board USS Utah (AG-16), 23 April 1940, during an inspection tour of the U.S. Fleet.

    U.S. Naval Historical Center Photograph.

    Online Image: 49KB; 605 x 765 pixels


    Photo #: NH 56952

    Secretary of the Navy Charles Edison

    (center)

    On board USS Utah (AG-16), 23 April 1940, during an inspection tour of the U.S. Fleet.
    He is flanked by Rear Admiral Ernest J. King (left), Commander, Patrol Force, U.S. Fleet, and Captain Morton L. Deyo, Aide to the Secretary of the Navy.

    U.S. Naval Historical Center Photograph.

    Online Image: 64KB; 740 x 615 pixels
