Photo # NH 46141:  Machine shop on board USS Milwaukee, 27 April 1916

Online Library of Selected Images:
-- U.S. NAVY SHIPS --

USS Milwaukee (Cruiser # 21), 1906-1917 --
Views on Board the Ship

The photographs on this page were all taken on 27 April 1916, while USS Milwaukee was in drydock at the Mare Island Navy Yard, California, and more than a month after she was assigned as tender to the Pacific Fleet's torpedo craft. Many of the installations shown in these views, especially the foundry and other shops, and perhaps the store rooms, appear to have been recently added to the ship to allow her to better perform this function.

This page features photographs taken on board USS Milwaukee (Cruiser # 21).

For other images concerning this ship, see:

  • Milwaukee (Cruiser # 21), 1906-1917.


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."

    Click on the small photograph to prompt a larger view of the same image.

    Photo #: NH 46143

    USS Milwaukee
    (Cruiser # 21)

    3"/50 gun battery on the port side of the ship's upper deck, at frame numbers 29 to 32. Photographed at the Mare Island Navy Yard, California, 27 April 1916.

    U.S. Naval Historical Center Photograph.

    Online Image: 110KB; 740 x 605 pixels


    Photo #: NH 46148

    USS Milwaukee
    (Cruiser # 21)

    3"/50 gun on the port side of the ship's upper deck, at frame numbers 29 to 32. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the Navy Yard buildings in the background.

    U.S. Naval Historical Center Photograph.

    Online Image: 95KB; 740 x 605 pixels


    Photo #: NH 46144

    USS Milwaukee
    (Cruiser # 21)

    Foundry on the ship's upperdeck, amidships at frame numbers 58 to 64. View looks aft. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the corrogated iron sides and roof of this structure.

    U.S. Naval Historical Center Photograph.

    Online Image: 85KB; 740 x 600 pixels


    Photo #: NH 46145

    USS Milwaukee
    (Cruiser # 21)

    Interior of the foundry located on the ship's upper deck, amidships at frame numbers 58 to 64. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the corrogated iron sides and roof of this structure, and its wooden frame work.

    U.S. Naval Historical Center Photograph.

    Online Image: 119KB; 740 x 600 pixels


    Photo #: NH 46146

    USS Milwaukee
    (Cruiser # 21)

    Storeroom located on the ship's main deck, amidships between frame numbers 57 and 64. View looks athwartships. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the steel mesh surrounding this space, and the six-inch projectile rack at right.

    U.S. Naval Historical Center Photograph.

    Online Image: 126KB; 740 x 605 pixels


    Photo #: NH 46138

    USS Milwaukee
    (Cruiser # 21)

    Storeroom on the ship's port side main deck, between frame numbers 72 and 84, looking aft. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the steel stock stowed in a rack inside the space.

    U.S. Naval Historical Center Photograph.

    Online Image: 126KB; 740 x 600 pixels


    Photo #: NH 46139

    USS Milwaukee
    (Cruiser # 21)

    Storeroom on the ship's starboard side main deck, between frame numbers 72 and 84, looking aft. Photographed at the Mare Island Navy Yard, California, 27 April 1916.

    U.S. Naval Historical Center Photograph.

    Online Image: 107KB; 740 x 605 pixels


    Photo #: NH 46142

    USS Milwaukee
    (Cruiser # 21)

    Carpenter shop on the starboard side of the gun deck, at frame numbers 12 to 27. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the electric drill press at left.

    U.S. Naval Historical Center Photograph.

    Online Image: 91KB; 740 x 600 pixels


    Photo #: NH 46141

    USS Milwaukee
    (Cruiser # 21)

    Machine shop on the starboard side of the gun deck, at frame numbers 27 to 35. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the planing machine in the foreground, and leather power transmission belts.

    U.S. Naval Historical Center Photograph.

    Online Image: 125KB; 740 x 605 pixels


    Photo #: NH 46147

    USS Milwaukee
    (Cruiser # 21)

    Machine shop located on the port side of the ship's gun deck, at frame numbers 27 to 38. Photographed at the Mare Island Navy Yard, California, 27 April 1916.

    U.S. Naval Historical Center Photograph.

    Online Image: 105KB; 740 x 600 pixels


    Photo #: NH 46137

    USS Milwaukee
    (Cruiser # 21)

    Ship's pay office, located on the starboard side of her berth deck at frame numbers 90 to 94. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note differing style of chairs, wire document baskets, leather waste paper recepticle and fancy light fixture.

    U.S. Naval Historical Center Photograph.

    Online Image: 119KB; 740 x 600 pixels


    Photo #: NH 46140

    USS Milwaukee
    (Cruiser # 21)

    Ship's dental office, located on the port side of the berth deck at frame numbers 15 to 20. Photographed at the Mare Island Navy Yard, California, 27 April 1916.
    Note the dental treatment chair in the foreground, and the electric fan on the desk in the left background.

    U.S. Naval Historical Center Photograph.

    Online Image: 102KB; 590 x 765 pixels
